Temperature prefabrication range: room temperature～50℃
Display resolution:0.1℃.
Temperature control accuracy: ±0.3℃
Timing prefabrication range: 1min～900min
Time control accuracy: ±0.5min
Work noise: ＜60db
Number of lifting baskets: 1 set
Lifting frequency of basket: (30～31) times/min.
Lifting distance of basket: (55±1) mm
Minimum spacing from screen to beaker bottom: 25mm±2mm
Mesh size: standard configuration 2mm,
(optional for 0.425mm and 1mm bore diameters)
Power supply：220V50Hz
Total power：600W
Overall dimensions：L*W*H 260mm*300mm*440mm

Main features

① 1 set of basket.
② The instrument controls the bath temperature at 37.0℃ automatically (prescribed by Pharmacopeia). High-precision digital electronic sensor is adopted to ensure the high precision and high accuracy of water bath temperature without the need for calibration.
③ The instrument sets the lifting time of baskets to be 15min automatically, which can also be reset at any time.
④ It adopts the computer control technology which is centered on SCM to control two performance parameters including bath temperature and working time intelligently.
⑤ The instrument can monitor bath temperature, give over-temperature alarm and protect itself automatically.
