1. Microcomputer control, touch panel, LCD display, automatic memory of operating parameters, RCF direct start, convenient operation and use
2. High torque brushless variable frequency motor drive, European imported ultra high speed bearings, smooth operation, maintenance free
3. Multi layer vibration reduction structure, low vibration and noise, environmentally friendly
4. Steel body, stainless steel centrifugal chamber, imported key components, corrosion-resistant, easy to clean, durable
5. Protection functions such as over temperature, over speed, door cover, and imbalance, as well as life calculation functions for the main engine and rotor, ensure safety
6. Exclusive high-power heating design, fast heating up; Exclusive SCT speed control technology, fast acceleration and deceleration, time-saving and efficient
7. From 0 to 9 levels, there are 10 different lifting speeds to choose from or directly input the lifting speed time. It can store 40 custom working modes to achieve optimal centrifugation
8. Made according to the requirements of GB/T6533-86 standard, it is an ideal separation equipment for moisture determination in the petroleum extraction industry and research units.
| Model | TD5Y |
| Max Speed | 4000r/min |
| Max RCF | 3100xg |
| Max Capacity | 8x15ml;4x100ml |
| Temperature Range | RT+10℃~80℃; Temp Accuracy:±2℃ |
| Time Range | 0-99min |
| Power | AC220V 50HZ 20A |
| Noise | ≤58dBA |
| Dimension | 520x550x480mm |
| Weight | 85kg |
